Sortex

FIELD OF USE

The machine will have 13 feeding channels, each 300 mm wide. Secondary (complex) mechanics will have troubleshooting capabilities.

Each module will be equipped with a two-way vision system. The machine will have doors visible from the front inspection area, allowing for the control of accepted and rejected product flow. The machine, with independent precision control and purification techniques for any type of spot damage, will be capable of distinguishing between colors or defects. We have used two 5400 CCD cameras in each channel.

During the process, the first 6 channels will be used for sorting, the second 5 channels for coarse sorting (Resort), and the third 2 channels for final sorting.

FEATURES AND ADVANTAGES

  • High performance.
  • Minimal volume.
  • Low air consumption.
  • Minimal maintenance requirements, minimal material needs.
  • Compact design.
  • Stable operation.
  • Long-lasting consumables, maximum safety.
  • Easy to use and configure.

recent projects

  • Pneumatic Cyclone

    It is used to separate the product by centrifuging the air mixture.

  • Pipe Magnet

    It provides continuous cleaning and separation by relatively cleaning the particles in the product to be processed.
